Midwest Automotive Designs Passage Motor Home Class B - Diesel RVs For Sale

Previous
Next
1 of 16

It's time to travel in luxury anywhere and everywhere you go in a Passage Class B diesel motorhome by Midwest Automotive Designs.



The Passage is built on a Mercedes-Benz Sprinter chassis with a Mercedes-Benz diesel engine. With the interior convenience of a Suburban tankless water heater, a convection microwave, a 12 Volt/110 Volt refrigerator, and a wet bath, you will not miss any of your home amenities while on the go. You will love the look of the hand-stitched leather seating and polished wood veneer cabinets, as well as the solid surface countertops. You also get an LED HDTV to stay entertained wherever you are!



When you are ready to venture out to your favorite vacation spot, pack up your family and gear in the Midwest Automotive Designs Passage Class B diesel motorhome and enjoy luxury living!

  • Passage FD2 Lounge 170 STD

    Passage FD2 Lounge 170 STD Floorplan Image

    Midwest Automotive Designs Passage Class B diesel motorhome FD2 Lounge 170 STD ... more about Passage FD2 Lounge 170 STD

    Have a question about this floorplan? Contact Us

    Specifications

    Length 22 ft 6 in
    Ext Width 7 ft 8 in
    Ext Height 9 ft 6 in
    Int Height 6 ft 3 in
    Gross Weight 9480 lbs
    Dry Weight 6413 lbs
    Cargo Weight 3067 lbs
    Fresh Water Capacity 32 gals
    Grey Water Capacity 27 gals
    Black Water Capacity 15 gals
    Tire Size 16"
    Generator 2.5 KW LPG
    Fuel Type Diesel
    Engine Mercedes-Benz
    Chassis Mercedes-Benz Sprinter
    Horsepower 188 hp
    Fuel Capacity 24.5 gals
    Wheelbase 170 in
    Torque 325 ft-lb
    Refrigerator Type 12 Volt/110 Volt Stainless Steel
    Convection Cooking Yes
    Number of Awnings 1
    LP Tank Capacity 15.1 gals
    AC BTU 13500 btu
    TV Info LED HDTV
    Awning Info Power with LED Light
    Gross Combined Weight 9480 lbs
    Shower Type Wet/Bath Shower
    Electrical Service 30 amp
  • Passage MD2 Lounge 170 EXT

    Passage MD2 Lounge 170 EXT Floorplan Image

    Midwest Automotive Designs Passage Class B diesel motorhome MD2 Lounge 170 EXT ... more about Passage MD2 Lounge 170 EXT

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 24 ft 6 in
    Ext Width 7 ft 8 in
    Ext Height 9 ft 6 in
    Int Height 6 ft 3 in
    Exterior Color White, Grey, Black
    Gross Weight 9480 lbs
    Dry Weight 6413 lbs
    Cargo Weight 3067 lbs
    Fresh Water Capacity 32 gals
    Grey Water Capacity 27 gals
    Black Water Capacity 15 gals
    Tire Size 16"
    Generator 2.5 KW LPG
    Fuel Type Diesel
    Engine Mercedes-Benz
    Chassis Mercedes-Benz Sprinter
    Horsepower 188 hp
    Fuel Capacity 24.5 gals
    Wheelbase 170 in
    Torque 325 ft-lb
    Refrigerator Type 12 Volt/110 Volt Stainless Steel
    Convection Cooking Yes
    Cooktop Burners 1
    Number of Awnings 1
    LP Tank Capacity 15.1 gals
    Water Heater Type Suburban Tankless
    AC BTU 13500 btu
    TV Info LED HDTV
    Awning Info Power with LED Light
    Gross Combined Weight 9480 lbs
    Shower Type Wet/Bath Shower
    Electrical Service 30 amp
  • Passage MD4 Lounge 170 EXT

    Passage MD4 Lounge 170 EXT Floorplan Image

    Midwest Automotive Designs Passage Class B diesel motorhome MD4 Lounge 170 EXT ... more about Passage MD4 Lounge 170 EXT

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 2
    Length 24 ft 6 in
    Ext Width 7 ft 8 in
    Ext Height 9 ft 6 in
    Int Height 6 ft 3 in
    Exterior Color White, Grey, Black
    Gross Weight 9480 lbs
    Dry Weight 6413 lbs
    Cargo Weight 3067 lbs
    Fresh Water Capacity 32 gals
    Grey Water Capacity 27 gals
    Black Water Capacity 15 gals
    Tire Size 16"
    Generator 2.5 KW LPG
    Fuel Type Diesel
    Engine Mercedes-Benz
    Chassis Mercedes-Benz Sprinter
    Horsepower 188 hp
    Fuel Capacity 24.5 gals
    Wheelbase 170 in
    Torque 325 ft-lb
    Refrigerator Type 12 Volt/110 Volt Stainless Steel
    Convection Cooking Yes
    Cooktop Burners 1
    Number of Awnings 1
    LP Tank Capacity 15.1 gals
    Water Heater Type Suburban Tankless
    AC BTU 13500 btu
    TV Info LED HDTV
    Awning Info Power with LED Light
    Gross Combined Weight 9480 lbs
    Shower Type Wet/Bath Shower
    Electrical Service 30 amp

Passage Features:

Standard Features



Interior Standard Features

  • Suburban Water Heater
  • 13,500 BTU Roof Top AC (shore-line / Gen)
  • Espar Coach Furnace
  • 2.5 KW LPG Generator
  • 2000 Watt Inverter / Charger / Transfer Switch
  • ECO Chassis Battery Charging System
  • Satellite TV Prep
  • Wi-Fi Prep
  • Multiple HDMI Input
  • Multiple 110 Volt Outlets
  • Multiple USB 12 Volt Chargers
  • Rear HD LED TV
  • Rear FM Radio
  • Rear Blue-Ray DVD/CD Player
  • Rear Speaker Upgrades
  • Digital Touch Screen Multi Plex Coach Controls
  • Overhead Courtesy Lighting
  • Smoke, LPG, CO Detectors
  • Fire Extinguisher
  • FanTastic Roof Fan w/Remote
  • Solid Surface Counter Tops
  • Molded Sink with Flush Mount Cover
  • Induction Cook Top
  • Stainless Steel Refrigerator 12 Volt / 110 Volt
  • Stainless Steel 110 Volt Convection Microwave
  • Removable Table / Dinette
  • Cabinets and Wardrobe With Hidden Hinges
  • Soft Touch Automotive Color Keyed Walls and Headliner
  • Composite 1/pc Flooring system Valances with Wood Inlay and Indirect Lighting
  • Coordinated Door Panels
  • Custom Dash and Door Handle Wood Grain Upgrade
  • Custom Floor Mats W/Non Slip Rubber Backing
  • Driver and Passenger Deluxe Seating Recover
  • Driver and Pass Front Swivel Seating
  • Custom Work Station Area Behind Driver Seat
  • Custom Maybach Style Seating With Seat Belts
  • Interior Entrance Grab Handle
  • Side and Rear Screen Doors
  • Power Folding Rear Sofa Bed
  • Under Sofa Storage
  • Rear Luggage Storage
  • Complete Insulation Package
  • Complete Privacy Shade Package
  • Front Privacy Window Close Outs
  • Shower With Dual Entry Solid Doors
  • Solid Surface Sink in Bath
  • Retractable Clothes Line
  • Shower Curtain
  • Porcelain Toilet
  • Power Bath Vent
  • Fresh and Grey Holding Tank Heat Pads
  • Sani Flush Black & Grey Tank Flush
  • 32 Gal. Fresh Water Holding Tank
  • 27 Gal. Grey Water Holding Tank
  • 15 Gal. Black Water Holding Tank

Exterior Standard Features

  • Dark Tinted Side and Rear Windows
  • Tip-Out Windows
  • Fiberglass Running Board with Step
  • Color Keyed Bumpers and Body Moldings
  • Rear Hitch with Wiring Package
  • 16″ Aluminum Wheel Package
  • Rear Back-Up Camera System
  • Power Awning with LED Light
  • LED Patio Light
  • 110 Volt Outlet
  • HD Digital Air TV Antenna
  • 100 Watt Roof Top Solar Charging System
  • Dual Battery Charging System with Monitor
  • Lifeline AMG Deep Cycle 225 Amp Hour Battery System
  • 30 Amp 110 Volt Shore Line Power Hookup with Cord
  • LP Remote Fill 15.1 gal Capacity
  • All In One Utility Bay Houses the Following Features
  • Cable TV Input
  • Water Fill
  • Exterior Shower
  • Macerator Pump with Power Gates and Power Hose Reel

Available Options

  • Power Drop Down Bed
  • AMG Single or SLS Double Needle Diamond Pattern Seating
  • Satin Interior Wood Finish
  • Front Spoiler With Lights
  • Wireless Internet Router & Apple TV
  • 300 Amp Hr. Lithium Batteries w/ BMS & Chassis Battery Boost
  • 600 Amp HR Lithium Eco-Freedom Package W/BMS & Battery Boost
  • Complete Roof Rack w/ Ladder
  • VB Air Ride System
  • 4×4 Chassis Upgrade
  • All Terrain Off Road Tires 16″ Black Rims

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Manu-Facts:

Midwest Automotive Designs, LLC is the most respected name in Sprinter Van custom conversions. From our headquarters in Elkhart, Indiana, we’ve been creating custom luxury vans under the Freightliner and Mercedes-Benz marques ever since the Sprinter was introduced here in 2001. Our pioneering work and artistry has led to our being chosen by Mercedes-Benz as an approved upfitter of their luxury Sprinter Vans. Our experience means we’re uniquely able to enhance the legendary quality, performance and safety engineering of the Mercedes-Benz Sprinter chassis. Our Sprinter Van conversions are available in three wheelbase lengths, two roof heights, and a range of elegant colors. But that’s only the beginning. Through our in-house engineers, designers and craftsmen – including our own custom seating division and wood processing department – we can do what others can't. From personal use luxury vans to corporate limousine vans, Midwest assures you of the very best in quality, comfort and durability. Whether it is a fleet of 100 or a one-of-a-kind luxury conversion, there is no request too large and no project too small. Your complete satisfaction is our mission, and we invite our customers to become completely involved in the build process. At Midwest Automotive Designs, our success has been built on service, integrity, design and value. These aren’t just marketing buzzwords to the men and women who handcraft our luxury vans – they’re the aspiration qualities that keep us jumping out of bed every morning, ready to work on our next masterpiece. Your masterpiece.
